Touchscreens with 9-33V support

7 inch touchscreen metal
- High resolution multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 181 x 123 x 42 mm

8 inch touchscreen metal (4:3)
- 4:3 multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 199 x 159 x 37 mm

10 inch touchscreen
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Wall, desktop
- External dimensions: 242 x 169 x 32 mm

10 inch touchscreen metal (4:3)
- 4:3 multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 228 x 183 x 41 mm

10 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 249 x 170 x 40 mm

10 inch touchscreen metal (high brightness)
- High-brightness Full-HD multi-touch panel
- Input: HDMI, DisplayPort, USB-C, VGA
- Mounting: Flush, embedded, panel mount
- External dimensions: 263 x 191 x 41 mm

12 inch touchscreen
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Wall, desktop
- External dimensions: 284 x 177 x 27 mm

12 inch touchscreen metal (4:3)
- 4:3 multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 280 x 223 x 44 mm

12 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, wall, desktop
- External dimensions: 297 x 185 x 41 mm

12 inch touchscreen metal (high brightness)
- High-brightness Full-HD multi-touch panel
- Input: HDMI, DisplayPort, USB-C, VGA
- Mounting: Flush, embedded, panel mount
- External dimensions: 307 x 201 x 41 mm

13 inch touchscreen
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Wall, desktop
- External dimensions: 318 x 200 x 34 mm

13 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 328 x 205 x 41 mm

15 inch touchscreen
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Wall, desktop
- External dimensions: 373 x 232 x 33 mm

15 inch touchscreen metal (4:3)
- 4:3 multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 345 x 268 x 47 mm

15 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 386 x 238 x 41 mm


15 inch touchscreen (high brightness)
- High-brightness Full-HD multi-touch panel
- Input: HDMI, DisplayPort, USB-C, VGA
- Mounting: Flush, embedded, panel mount
- External dimensions: 407 x 256 x 44 mm

17 inch touchscreen metal (5:4)
- 5:4 multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 384 x 316 x 46 mm

17 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 430 x 263 x 42 mm

19 inch touchscreen metal (5:4)
- 5:4 multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 421 x 346 x 46 mm

19 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 481 x 294 x 45 mm

22 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 522 x 317 x 45 mm


22 inch touchscreen metal (high brightness)
- High-brightness Full-HD multi-touch panel
- Input: HDMI, DisplayPort, USB-C, VGA
- Mounting: Flush, wall, desktop, embedded, panel mount
- External dimensions: 535 x 334 x 44 mm

24 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 576 x 348 x 45 mm

27 inch touchscreen metal
- Full HD multi-touch panel
- Input: HDMI, VGA, BNC, RCA
- Mounting: Flush, embedded, wall, desktop
- External dimensions: 657 x 393 x 44 mm
Beetronics 9-28 volt touchscreen monitors are designed for professional use. The 9-28v touchscreens can be connected directly to the 9-28 volt mains and are therefore ideal for maritime and automotive applications.
Professional 9-28V touch displays
The 9-28V screens have a high resolution IPS panel which provides a superior picture quality and a wide viewing angle of 178 degrees. The touchscreens are suitable for continuous use and the backlight brightness is easy to adjust with the optional external dimmer.
Mounting the 9-28V touchscreens
The 9-28V monitors have numerous mounting options making them easy to install. Each monitor is equipped with a fully collapsible stand that can be easily removed to get access to the 75mm VESA mount. This allows the touchscreens to be attached to a universal bracket. The metal version comes standard with mounting strips with which they can be easily installed.
Would you like more information about 9-28V touchscreens? Contact our experts. We would be happy to advise you on buying a new 9-28V touch display.
